SMT Stencil Inspection Machine
SMT stencil & precision QA
SMT Stencil Inspection Machine
200 W total power · 24 × 7 × 365 operation
Purpose-built SMT stencil inspection platform combining high-magnification vision with a comprehensive measurement toolkit designed for precision QA in modern SMT stencil production.
Applications
- SMT stencil dimensional and aperture QA
- Precision metal component measurement
- Micro-aperture geometry validation
Key advantages
- Total power consumption as low as 200 W
- Comprehensive measurement toolset
- Concentric / two-point / three-point / two-point-defined circles
- Line, arc, straightness, cross-line and IC-pin pitch tools
- Polygon and center-distance measurement
Technical SpecificationsAll values typical
| Parameter | SMT Stencil Inspection Machine |
|---|---|
| Power | 200 W total |
| Operating time | 24 × 7 × 365 |
| Measurement toolkit | Points · lines · arcs · circles · IC pin pitch · polygons |
